Description
The Control Case for BlueROV2 is a portable and robust solution for operating and monitoring the BlueROV2. Designed for field use, it integrates a high-performance PC, a sunlight-readable 18.5-inch touchscreen monitor, and an intuitive wireless keyboard with a built-in mousepad. The system ensures seamless ROV control with a Fathom-X tether interface, reliable power options, and a built-in UPS function for uninterrupted operations.
Housed in a durable polypropylene case with an epoxy-coated aluminum panel, the control case is designed to withstand harsh environments while maintaining a compact and portable form factor.
Included Contents
1x Control case
1x Power cable C13 (230 VAC)
1x Power cable with open ends (9-36 VDC)
Specifications
| Specification | Details |
| Case | Polypropylene case with removable lid |
| Panel | Epoxy-coated aluminum panel with monitor and connections |
| Dimensions | 607 x 475 x 275 mm |
| Weight | 18.4 kg |
| Power Inputs | 100-240V AC / 9-36V DC |
| Battery Charger | Automatic charger with UPS function |
| PC | Intel Core i5-12500 (3.0GHz, 6C/12T, LGA1700, 65W, 18MB) |
| Memory | 16 GB RAM |
| Storage | 240 GB SSD |
| Connectivity | WiFi |
| ROV Connection | Fathom-X Tether Interface |
| Monitor | 18.5” Touchscreen (10-point capacitive touch) |
| Monitor Brightness | 1000 cd/m², sunlight readable |
| Auto Dimming | Yes, with light sensor |
| Contrast Ratio | 1000:1 |
| Speakers | 2 x 3W built-in speakers |
| Protection | IP51 (Dust-resistant, protected against vertical water droplets) |
| Supplied With | Power cord (IEC C13) & Power cord with open leads (9-36V DC) |
